Description:
Tight Buffer Fiber is produced as that fiber is sheathed by buffer material. The selection of top-quality fiber,the specific production equipment and the accurately designed die make the performance of product.
Characteristics:
Good uniformity of the outer diameter of tight buffer fiber and excellent strippability.
Good performance of flame-retardant.
Low induced attenuation within the operating temperature range.
Excellent geometrical dimension of the fiber.
Applications
Indoor cable.
Making jumper, pigtail.
Data communication.
Technical Parameters:
Fiber CoatingDiameter (um) | TBF Diameter (um) | TBF Weight (kg/km) | Tensile Strength Long/Short term(N) | Crush Resistance Long/Short term(N/100mm) | Bending Radius Dynamic/Static(mm) | Coating Strip (N) |
---|---|---|---|---|---|---|
245±7 | 900±5 | 0.9 | 3/6 | 100/500 | 20D/10D | ≤13.3 |
